Utsolgt, men kan bestilles
Glamping for business ▪ Isolert ▪ Flerlagsvegg
78m2 GLAMPING Ø10m ICO F4 H5m
DOME PROPERTIES :
Height: 5 m
Diameter: 10 m
Floor Area: 78 sqm
Cover Area: 156 sqm
Utsolgt, men kan bestilles
- Sertifisert konstruksjon
- Produsert i Litauen
- Konsultasjon 2–4 t
DOME PACKING
| Vekt | 1200 kg |
|---|---|
| Dimensjoner | 120 × 230 × 200 cm |
| packing | 2x Euro Pallet |
| shipments | Cargo Transportation, Door-To-Door, Sea containers |
BESTILLINGSNOTATER
Hva som er inkludert i grunnpakken
Konfigurasjon
- Individuell kuppelprojektering og produksjon.
- Gjennomsnittlig produksjonstid – 5–7 uker.
- Kuppelramme, kledning, isolasjon og innvendige lag etter valgt konfigurasjon.
- Konstruksjonstegninger, monteringsanvisning og delenummerering.
Levering & garanti
- Pakken pakkes på transportpall.
- Forsendelse fra GEODOMAS-lager i Vilnius.
- Leveringsbetingelser: EXW Vilnius, Litauen.
- Levering og montering er ikke inkludert i prisen.
- 3 års garanti på konstruksjonen.
- Projektert levetid for materialer – opptil 5–50 år.
LIVE 3D
-
Metalinė, cinkuota sferinės formos konstrukcija | Kupolo formos paviljono rėmas pagamintas iš cinkuoto plieno, vieno varžto jungtys , apatinės jungtys kupolo tvirtinimui.
Geodezinio kupolo metodas leidžia sukurti lengvą, gerai apsaugotą ir labai stabilią erdvę. Pagrindinis geodezinių kupolų privalumas yra tolygus įtempių pasiskirstymas visuose rėmo mazguose. „Glamping Domes“ nereikia jokių kolonų, apkrovos sienų ar stulpelių, kad klientai galėtų naudotis maksimaliu turimu plotu. Naudojant plieninius konstrukcinius elementus, struktūra tampa tvari atsižvelgiant į oro veiksnius ir apkrovas.
Kiekviena geodezinė kupolo konstrukcija suprojektuota pagal apkrovos skaičiavimus. Tai savo ruožtu užtikrina saugumą ir ilgaamžiškumą. Mūsų konstrukcijų inžinieriai gali apskaičiuoti maksimalias įrangos apkrovas, atitinkančias regionines normas.
-
Dome cover, tensioned outdoor membrane
For geodesic dome covers we use highest-quality PVC tent fabrics. All fabrics are certified and meet European fire-resistance and quality standards.
The removable dome cover is known for its advantages and long service life.
-
Panoramic cover window, transparent PVC membrane
Tinted panoramic PVC window membrane designed for glamping tents. Transparent PVC fabric that transmits sunlight excellently and illuminates the entire dome.
- Temperature range: from -40 °C to +80 °C
-
Opening gravity ventilation elements
Upper air exhaust openings and lower air supply openings. Openings are insulated against leakage.
All multi-layer wall chambers have special openings for condensation and air ventilation.
The gravity ventilation system provides natural air circulation.
-
STANDARD PVC PROFILE DOORS | SINGLE DOORS
The main advantage of 71 mm PVC profile doors is excellent insulation. They are impact-resistant and protect the home from break-ins.
- PVC doors have multi-point security locks.
- They are strong and secure.
-
-
Multi-layer dome wall thermal insulation with two 100 cm chambers
This is a thin, highly reflective, multi-layer insulation system. Reflective thermal insulation materials are produced using NASA-developed technology that protects spacecraft from extreme external factors.
-
Primary quality material for wall finishing. Wall Carpet – sound-absorbing material in the multi-layer wall system.
Various material types are available, such as polypropylene or nylon, or material blends. It can be loop pile, cut pile, roll or broadloom.
-
Vidaus apdailos langas | Daugiasluoksnė siena | Glamping mobilus.
Tai 100% poliesteris su PVC uždangalu, Ypač neplyšantis / tvirtas, atsparus vandeniui, plyšimui sunkusis PVC tentas.
- Neplyštantis/ tvirtas;
- Atsparus vandeniui, plyšimui sunkusis PVC tentas;
